商品の詳細:
お支払配送条件:
|
| フレーム素材: | 金属 | 金属の種類: | 鋼鉄 |
|---|---|---|---|
| 加圧処理木材タイプ: | 熱処理済み | フレーム仕上げ: | 粉体塗装 |
| 特徴: | 容易に、集まっている、支持できる、扱われるFSC友好的なのECO圧力 | 使用法: | 庭の塀、ハイウェーの塀、スポーツの塀、農場の塀、刑務所の塀 |
| タイプ: | の防御フェンス、私道のゲート、塀のアクセス機構囲うこと、格子垣及びゲート | サービス: | 、3Dサンプル モデル模倣する、3D取扱説明書、ビデオはの取付ける |
| パネルの高さ: | 2.1m、2.4m、2.9m | パネル幅: | 2.5m、2.9m |
| 線径: | 3.85/4mm | オープニング: | 76.2×12.7mm |
| 表面処理: | ポリ塩化ビニールは電流を通されて塗るか、または熱浸った | 商業バイヤー: | デパート |
| 色: | 緑RAL6005、黒いRAL9010、ブラウンRAL等 | デザインスタイル: | の農家産業 |
| 電子メール: | devin@industrialmetalmesh.com | WhatsAPP: | +8615369013183 |
| ハイライト: | 358 metal welded wire mesh fence,PVC coated high security fence,outdoor garden barbed wire panel |
||
|
Mesh
|
Wire Diameter
|
Panel Width
|
Panel Height
|
Post Type
|
|
|
76.2x12.7mm
75x12.5mm 75x25mm 75x50mm |
Horizantal Wire: 3.2, 3.5, 4mm
Vertical Wire: 4mm |
1m-3m
popular: 2.2m/2.5m/3m |
1m-6m
popubr: 2.5m/3m |
Square Post(SHS) 60x60x2/2.5/3mm 80x80x2/2.5/3mm
|
Roctangular Post(RHS) 40x60x2/2.5/3.0mm 40x80x2/2.5/3.0mm 60x80x2/2.5/3.0mm
|
|
Surface Treatment: hot dipped galvanized, galvanized + powder coated
|
|||||
|
V-top: including angle iron, barbed wire,razor barbed wire
|
|||||
|
Connecting Methods: iom bar, hexagonal clamp, screws
|
|||||
|
Color: RAL 6005 green, RAL 7016 gray, All RAL color can be customized
|
|||||
| Horizontal Wire and Vertical Wire With V Fold 358 Security Fence | ||||||
| Mesh Opening | Wire Thickness | Panel Width | Panel Height | Number of Folds | Post Type | |
|
76.2*12.7mm (3''*0.5'') |
3.0mm or |
2.0m or 2.50m |
1830mm | 3 | Square Post(SHS) 50X50x1.5/2.0mm 60x60x1.5/2.0mm 80x80x1.5/2.0mm |
Rectangular Post(RHS) 40x60x1.5/2.0mm 40x80x1.5/2.0mm 60x80x1.5/2.0mm 80x100x1.5/2.0mm |
| 1930mm | 3 | |||||
| 2030mm | 4 | |||||
| 2230mm | 4 | |||||
| 2430mm | 4 | |||||
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating | ||||||
| Color: RAL 6005 green, RAL 7016 gray, RAL 9005 black,All RAL color can be customized. | ||||||
| Note: The fence can be customized according to your required if above specification is not satisfied with you | ||||||
| Horizontal Wire and Vertical Wire 358 Security Fence | |||||
| Mesh Opening | Wire Diameter | Height of Fence | Width of Fence | Post Type | |
| 12.7x76.2mm (0.5'' x 3'') |
3/3.5/4mm | 1.2-2.5m | 2.0-3.1m | Square Post(SHS) 60x60x2.0/2.5/3.0mm 80x80x2.0/2.5/3.0mm |
40x60x2.0/2.5/3.0mm 40x80x2.0/2.5/3.0mm 60x80x2.0/2.5/3.0mm |
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating | |||||
| Color: RAL 6005 green, RAL 7016 gray, All RAL color can be customized. | |||||
| Note: The fence can be customized according to your required if above specification is not satisfied with you | |||||
