商品の詳細:
お支払配送条件:
|
| 穴の形状: | 四角 | ワイヤーゲージ: | 2.0-4.0mm |
|---|---|---|---|
| 応用: | 建設用ワイヤーメッシュ | 材料: | 低炭素の鉄ワイヤー、電流を通された鉄ワイヤー |
| タイプ: | 溶接メッシュ | 絞り: | 1/2" |
| 表面処理: | 溶融亜鉛メッキ | 幅: | 0.5-2m、0.5-1.8m、300mm-2500mm、0.5mから2.2m、1.2m |
| 長さ: | 5m | 使用法: | 建物、構造 |
| パッキング: | パレット | 製品名: | 電流を通された/ポリ塩化ビニール溶接された金網は溶接された金網に塗った |
| 色: | 銀 | ||
| ハイライト: | PVC coated welded wire mesh,hot dipped galvanized steel mesh,low carbon iron wire mesh |
||
Welded Wire Mesh Low Carbon Steel Iron PVC Coated Hot Dipped Galvanized
Welded wire mesh is one popular materials in concrete, construction and industry. It is made of low carbon steel wire, PVC coated wire and stainless steel wire, after welding or before welding and surface zinc treating .The welded wire mesh are the most excellent anti-corrosion resistance among all the steel wire mesh products, it is also the most versatile wire mesh due to its wide application in different fields.
Hot dipped galvanized before weldingHot dipped galvanized after welding Electro galvanzied before weldingElectro galvanzied after welding
|
welded wire mesh rolls
|
||
|
Opening
|
Wire diameter
|
Available Width
|
|
1/4" x 1/4"
|
0.45mm-0.7mm
|
300mm-1830mm
|
|
3/4" x 3/4"
|
0.7mm-2.0mm
|
300mm-1830mm
|
|
3/8" x 3/8"
|
0.7mm-1.1mm
|
300mm-1830mm
|
|
5/8" x 5/8"
|
0.8mm-1.2mm
|
300mm-1830mm
|
|
1/2" x 1/2"
|
0.45mm-1.6 mm
|
300mm-1830mm
|
|
1" x 1"
|
0.7mm-3.0mm
|
300mm-2000mm
|
|
1" x 1/2"
|
0.8mm-1.6mm
|
300mm-1828mm
|
|
1-1/2" x 1-1/2"
|
0.7mm-3.5mm
|
300mm-1828mm
|
|
1" x 2"
|
1.6mm-2.1mm
|
300mm-1828mm
|
|
2" x 2"
|
0.7mm-4.0mm
|
300mm-2500mm
|
|
2" x 3"
|
1.5mm-3.5mm
|
300mm-2000mm
|
|
2" x 4"
|
2.0mm-4.0mm
|
300mm-1828mm
|
|
3" x 3"
|
1.0mm-4.5mm
|
300mm-2500mm
|
|
3" x 4"
|
1.5mm-4.5mm
|
300mm-2000mm
|
|
4" x 4"
|
1.0mm-4.5mm
|
300mm-2500mm
|
|
5" x 5"
|
2.5mm-4.5mm
|
300mm-2500mm
|
|
6" x 6"
|
2.5mm-4.5mm
|
300mm-2500mm
|
| Opening (inch) |
Opening (mm) |
Wire Diameter | Wire Diameter | Panel Length | Panel Width |
| 1"x1" | 25mmx25mm | 14#-11# | 2.0mm-3mm |
|
|
| 2"x1" | 50mmx25mm | 14#-8# | 2.0mm-4mm | ||
| 2"x2" | 50mmx50mm | 14#-8# | 2.0mm-4mm | ||
| 3"x2" | 75mmx50mm | 14#-6# | 2.0mm-5mm | ||
| 3"x3" | 75mmx75mm | 14#-6# | 2.0mm-5mm | ||
| 4"x2" | 100mmx50mm | 14#-4# | 2.0mm-6mm | ||
| 4"x4" | 100mmx100mm | 14#-4# | 2.0mm-6mm | ||
| 5"x5" | 125mmx125mm | 14#-4# | 2.0mm-6mm | ||
| 6"x6" | 150mmx150mm | 14#-4# | 2.0mm-6mm |
|
Galvanized welded mesh panel
|
|||
|
Hole size
|
Wire diameter
|
Panel sizes
|
|
|
In Inch
|
In mm
|
In mm
|
Common sizes :
3' x 6' , 4' x 8' , 5' x 10'
1 x 2m ,2 x 2.9m ,
2 x 4m
Other sizes can be made as request .
|
|
1/2'' x 1/2''
|
12.7 x 12.7mm
|
1.0mm-2.0mm
|
|
|
1'' x 1''
|
25.4 x 25.4mm
|
1.5mm-3.5mm
|
|
|
1'' x 2''
|
25.4 x 50.8mm
|
2.0mm-5.0mm
|
|
|
5/4'' x 5/4''
|
31.8 x 31.8mm
|
2.0mm-4.0mm
|
|
|
3/2'' x 3/2''
|
38.1 x 38.1mm
|
2.0mm-5.0mm
|
|
|
2'' x 2''
|
50.8 x 50.8mm
|
2.0mm-6.0mm
|
|
|
2'' x 3''
|
50.8 x 76.2mm
|
2.0mm-6.0mm
|
|
|
3'' x 3''
|
76.2 x 76.2mm
|
3.0mm-7.0mm
|
|
|
4'' x 4''
|
101.6 x 101.6mm
|
3.0mm-8.0mm
|
|
|
5'' x 5''
|
127 x 127mm
|
4.0mm-9.0mm
|
|
|
6'' x 6''
|
152.4 x 152.4mm
|
4.0mm-10.0mm
|
|
